Product Overview

This premium off-centered ground stop is designed to ensure gates stop at the desired position, providing precise gate alignment for various applications. Its robust construction and adjustable features make it a reliable choice for securing gates effectively.

Features

• Surface mounted design, suitable for surface mounted drop bolts
• Maximum drop bolt axle diameter: Ø 20 mm
• Height adjustable: Distance between finished ground level and bottom of the gate: 20 to 45 mm
• Depth adjustable for different gate profiles: VSA - VSF - Keydrop: 40 to 60 mm; Electradrop: 40 to 50 mm
• Includes anchor pins for secure installation
• Material: Durable black anodized aluminium top plate

Dimensions & Specifications

Specification	Measurement
Maximum Drop Bolt Axle Diameter	Ø 20 mm
Height Adjustment Range	20 to 45 mm
Depth Adjustment Range for Gate Profiles	40 to 60 mm (VSA - VSF - Keydrop); 40 to 50 mm (Electradrop)
Weight	0.68 kg

Benefits

• Ensures precise alignment for smooth gate operation.
• Adjustable height and depth provide versatility for different installations.
• Durable construction ensures long-lasting performance.

FAQ

• What materials is the ground stop made of?
  The ground stop features a black anodized aluminium top plate for durability.
• How is the ground stop installed?
  It is surface mounted and comes with anchor pins for secure installation.
• Can this ground stop be used with various gate profiles?
  Yes, it is designed to accommodate different gate profiles with adjustable depth settings.
