Product Overview

This premium 180° adjustable hinge pair is designed for easy installation without the need for welding. It provides exceptional functionality and durability, making it ideal for gates of varying sizes.

Features

• Quick and easy installation with Quick-Fix or bolt-through fixing options.
• Vandal-proof design with an eyebolt and crossbolt for enhanced security.
• 180° opening capability for maximum accessibility.
• 15 mm height adjustment for precise gate alignment.
• 25 mm depth adjustment to accommodate various gate and post configurations.
• Durable U clamp and GRIP made from aluminum for longevity.
• Hot-dip galvanized eyebolt and crossbolt to resist corrosion.
• Maximum gate width compatibility of 2000 mm.

Dimensions & Specifications

Specification	Measurement
Height Adjustment	15 mm
Depth Adjustment	25 mm
Maximum Gate Width	2000 mm
Weight	1.63 kg
Length	110.0mm
Width	50.0mm
Depth	46.5mm

Technical Specifications

• Color: Black (9005)
• Material: Aluminum with hot-dip galvanized components
• Interchangeable for left and right turning gates

FAQs

Q: Can these hinges be used for both left and right turning gates?

A: Yes, the hinges are interchangeable and can be used for both left and right turning gates.

Q: What is the maximum width of the gate that can be accommodated?

A: The hinges can support gates with a maximum width of 2000 mm.

Q: How do I install these hinges?

A: Installation is straightforward and can be completed using Quick-Fix or bolt-through fixing without welding.
