Product Overview

This Premium Adjustable Aluminium Channel Side Fix is designed to accommodate glass panels ranging from 12mm to 21.52mm in thickness. With its innovative design, this channel allows for easy adjustments from one side, providing a hassle-free installation experience.

Key Features

• Length: 5000mm
• Adjustable from one side with 38mm of adjustment for precise alignment
• Innovative rotating wedge system for effortless adjustments
• Ensures glass panels are perfectly true and plumb

Dimensions & Specifications

Specification	Measurement
Length	5000mm
Glass Thickness Range	12mm to 21.52mm
Adjustment	38mm
Weight	30.5 kg
Width	127.0mm
Depth	65.0mm
Material	Aluminium
Material finish	Satin

Benefits

The adjustable feature of this channel allows for quick and efficient installation, making it ideal for various applications. The rotating wedge system simplifies the process of aligning glass panels, ensuring they are set accurately without hassle.

Safety Notice

** This product must be transported on a long pallet which covers three spaces to protect it from damage during transit. A delivery surcharge will apply to any order containing this product. **

FAQ

1. What is the maximum thickness of glass that can be used with this channel?

The channel is designed to accommodate glass thicknesses from 12mm to 21.52mm.

2. How do I adjust the glass once it is installed?

Simply use the adjustment tool to insert into the slot on the rotating wedge, allowing for precise alignment of the glass panels.

3. Is there a delivery surcharge for this product?

Yes, a £150 delivery surcharge will apply to any order containing this product due to its transportation requirements.
